You can choose any of the 4 USB ports available on the board.įor Arduino, you will use the USB port that you use to upload code from your computer (with the Arduino IDE) to your board. On the Raspberry Pi side, a simple USB connector is all you need. The easiest way is to use a USB cable between both board.
#Arduino nano pinout diagram serial serial
There are 2 ways to connect your Raspberry Pi and Arduino for Serial communication.
#Arduino nano pinout diagram serial how to
Let’s now see how to physically connect the 2 boards together. Then, both Raspberry Pi and Arduino will be able to send messages to each other. We’ll have to do some setup and write some code to make it work. What we’ll do here is almost the same, except that instead of your Arduino IDE, the other side of the Serial communication will be a Raspberry Pi board. You can receive and send data directly from the Serial monitor. When you use the Serial monitor, well, basically your Arduino IDE initiates a Serial communication with your Arduino. I’m sure you already know the Arduino Serial library, which allows you to log what’s happening in your code and get user input.

You’ve certainly already used Serial communication many times. You probably already know Serial communication You can also use the GPIOs (RX0/TX0) for an additional UART. Each will have a different device name (we’ll see how to find them later in this tutorial). On the Raspberry Pi, you can connect many Serial devices on the USB ports. For example the Arduino Mega has different Serials (Serial, Serial1, Serial2, Serial3) and the Arduino Zero has a native USB port only (use SerialUSB instead of Serial). The Arduino Uno board has one UART that you can use either with a USB cable or from the RX/TX pins (don’t use it with both at the same time). Usually you’ll use other protocols such as I2C and SPI when you need master-slaves configurations: for example when you have one Arduino board and multiple sensors or actuators. This is one of the main difference with master-slaves protocols, where only the master device can initiate a communication. Multi-master means that all connected devices will be free to send data when they want. Be reassured, there are libraries that will handle all the low layers for you. You are learning how to use the combo Raspberry Pi + Arduino to build your own projects?Ĭheck out Raspberry Pi and Arduino and learn step by step.īasically it’s an asynchronous multi-master protocol based on the Serial communication, which will allow you to communicate between the 2 boards. UART means “Universal Asynchronous Reception and Transmission”. More specifically, when you use Serial with Arduino and Raspberry Pi, you’re using the UART protocol.

The data will be sent sequentially, one bit at a time (1 byte = 8 bits), contrary to parallel communication, where many bits are sent at the same time. Serial communication is simply a way to transfer data.
